Touch Screen for Siemens SIMATIC Panel PC 677B 15" Repair

Regular price $249.99

Tax included. Shipping calculated at checkout.

With Glrassin 6 months warranty, Touch Screen for Siemens SIMATIC Panel PC 677B 15 INCH TFT Display HMI repair replacement. The PC677B touchscreen is 331mm in length and 250mm in width. Glrassin Spare Parts are used to repair HMI machines.

Siemens SIMATIC Panel PC 677 15" Touch TFT Display HMI Color display with backlighting:
– 15" TFT technology; 1024 x 768 resolution
• LEDs for power supply and temperature
• Front-mounted USB 2.0 interface for connecting external I/O devices. All fronts are also
available without USB interfaces accessible from the front

Free standard shipping is available for standard delivery of this touchscreen. Please carefully compare the dimensions with your machine and read the shipping and FAQ section before buying.  If you are not sure whether this part is suitable for your machine, send an email that attaches the picture of your old one with dimensions to us to confirm before you make the order. Our email address is sales@glrassin.com.

Touch Screen for Siemens SIMATIC Panel PC 677B 15" Repair Replacement

Specific parameters:

Warranty: 6 months Supply: Touch & Overlay
Size 15 INCH Resolution: 1024 x 768
Length: 331mm Width:
250mm
Wire 5
Model PC677B


Suitable for the following model:

Part Number  Description
6AV7872-0BC20-1AC0  SIMATIC Panel PC 677B 2x10/100/1000 Mbit/s Ethernet; 4 x USB V2.0, 1x serial (COM1); 15" Touch, 1024x 768; USB interface at the front 110/230 V AC power supply with NAMUR, power supply cable Europe; Core 2 Duo T5500, 1.66 GHz; 2 MB SLC, 2 x PCI; 1 GB DDR2 RAM; 160 GB SATA HDD 3.5", DVD +-R +-RW; PROFIBUS/MPI; Windows XP Prof. MUI (de,en,fr,es,it,ja,zh,ko)
6AV7802-0BB10-1AA0 SIMATIC PANEL PC 677 15" TOUCH, 1024X768; STANDARD AC110-230V, POWER CABLE EUROPE PENTIUM M770/1.6 GHZ; 533 MHZ FSB; 2MB SLC; 512MB DDR266 SDRAM (1X512MB); 80 GBYTE SATA HARD DRIVE (3.5") DVD-ROM; W/O OPERATING SYSTEM
6AV7872-0FC30-1AC0 SIMATIC Panel PC 677B 2x10/100/1000 Mbit/s Ethernet; 4x USB V2.0, 1x serial (COM1); 15" Touch; 1024x 768 with front-side USB-Schnittstelle 110/230 V AC power supply unit with NAMUR, power supply cable USA Core 2 Duo T5500, 1.66 GHz; 2 MB SLC, 2x PCI 2 GB DDR2 RAM; 160 GB SATA HDD 3.5" DVD+-R+-RW; PROFIBUS/MP, 2MB BUFF. SRAMI; Windows XP Prof. MUI (de,en,fr,es,it,ja,zh,ko), only with hard disk
6AV7802-0BB00-2AB0 SIMATIC PANEL PC 677 15" TOUCH, 1024X768; WITH FRONT SIDE USB INTERFACE AC110-230V, POWER CABLE EUROPE PENTIUM M770/1.6 GHZ; 533 MHZ FSB; 2MB SLC; 256MB DDR266 SDRAM (1X256MB); 80 GBYTE SATA HARD DRIVE 3,5" DVD+-RW+-R; WINDOWS 2000 PROF MUI (EN,GE,FR,IT,SP,JP,CHN,KOR)
