Touch Screen for Siemens SIMATIC Panel PC 677B 19" Repair

Regular price $399.99

Tax included. Shipping calculated at checkout.

With Glrassin 6 months warranty, Touch Screen for Siemens SIMATIC Panel PC 677B 19 INCH TFT Display HMI repair replacement. Glrassin Spare Parts are used to repair HMI machines.

Siemens SIMATIC Panel PC 677 19" Touch TFT Display HMI Color display with backlighting:
– 19" TFT technology; 1280 x 1024 resolution
• LEDs for power supply and temperature
• Front-mounted USB 2.0 interface for connecting external I/O devices. All fronts are also
available without USB interfaces accessible from the front

Free standard shipping is available for standard delivery of this touchscreen. Please carefully compare the dimensions with your machine and read the shipping and FAQ section before buying.  If you are not sure whether this part is suitable for your machine, send an email that attaches the picture of your old one with dimensions to us to confirm before you make the order. Our email address is sales@glrassin.com.

Touch Screen for Siemens SIMATIC Panel PC 677B 19" Repair

Specific parameters:

Warranty: 6 months Supply: Touch & Overlay
Size: 19 INCH Resolution:
1280 x 1024
Wire 5
Model PC677B


Suitable for the following model:

Part Number  Description
6AV7875-0FE50-1AC0
SIMATIC Panel PC 677B 2x10/100/1000 Mbit/s Ethernet; 4x USB V2.0, 1x serial (COM1); 19" Touch, 1280x 1024 with front-side USB-Schnittstelle 110/230 V AC power supply unit with NAMUR, power supply cable USA Core 2 Duo T7400, 2.16 GHz; 4 MB SLC, 2xPCI 4 GB DDR2 RAM; 160 GB SATA HDD 3.5" DVD+-R+-RW; PROFIBUS/MP, 2MB BUFF. SRAMI; Windows XP Prof. MUI (de,en,fr,es,it,ja,zh,ko), only with hard disk
6AV7804-0BB10-1AA0 SIMATIC PANEL PC 677 19" TOUCH, 1240X1024; STANDARD AC110-230V, POWER CABLE EUROPE PENTIUM M770/1.6 GHZ; 533 MHZ FSB; 2MB SLC; 512MB DDR266 SDRAM (1X512MB); 80 GBYTE SATA HARD DRIVE (3.5") DVD-ROM; W/O OPERATING SYSTEM
6AV7875-0BC20-1AC0 SIMATIC Panel PC 677B 2x10/100/1000 Mbit/s Ethernet; 4 x USB V2.0, 1x serial (COM1); 19" Touch, 1280 x 1024; USB interface at the front 110/230 V AC power supply with NAMUR, power supply cable Europe; Core 2 Duo T5500, 1.66 GHz; 2 MB SLC, 2 x PCI; 1 GB DDR2 RAM; 160 GB SATA HDD 3.5", DVD +-R +-RW, PROFIBUS/MPI; Windows XP Prof. MUI (de,en,fr,es,it,ja,zh,ko)
